18650 Silverfish Electric Bike Battery 36v 48v 10ah 30ah For Bicycle With BMS

18650 silverfish electric bike battery 36v 48v 10ah 30ah for bicycle with BMS

Product Description

Stable BMS system with short circuit protection, overcharge protection, over discharge protection and over current protection
Cycle life of at least 800 times
Performs well under different temperature and environmental conditions
No memory effect.
Suitable for e-bikes, electric bicycles, etc.
Full capacity battery, 100% quality test
Long cycle life, high energy density
Good consistency of capacity, resistance, voltage and platform time
Factory price, fast delivery, reliable quality
Light weight and small size

Silverfish Lithium Battery Installation Process and Instructions

Please use our discharge wire to connect to your controller. If you don't use our wire, please make sure your wire "+" and "_" are the same as our battery.
Battery Handle
90 degree rotation portable battery handle. Easier to carry the battery, easier to install and sense.
Install Battery Plate
Battery mounting plate. We will install this plate on the battery when it is shipped. You can hook it with a key and install it on the bicycle frame with screws. Then put the battery on it.
Easy to install, charge anytime, anywhere, you can remove the battery for charging, or charge the whole vehicle
Charging and discharging port Four-pin discharge port 2.5DC terminal charging port
Safety lock Key-controlled lock to prevent battery theft
Battery safety lock locks the battery to the frame
Anti-theft lock and control
4 bottom discharge ports
Charging socket The charging current of this socket cannot exceed 5 amps
Battery charge indicator Press the d) button and the indicator light will light up
1 red 2 green---100%
1 red 1 green---50%
1 red 0 green---20%

Steps

Install the battery holder to the bicycle with screws
Install the battery pack to the battery holder
Connect the battery converter to the bicycle controller.
Power on the battery
Confirm whether the battery can work.
Please send us a photo of the previous battery shape, or you can also tell us the size of the battery.
Need to take a photo of the discharge port to confirm the model
Make sure the voltage is consistent and the voltage is not mixed.
Check whether the battery body has a voltage mark. If
The battery body can confirm the voltage, please buy it.
If the voltage cannot be confirmed. If the battery body has no label, please take a photo of the parameters on the back of the charger and send it to us, our engineer will confirm it.
If the battery body has no label or is missing, and there is no charger. You need to check the controller and send us the controller parameters
